SSV单线递进式分配器，单线分配器

整体模块递进式分配器
•*高350BAR工作压力,无任何非金属密封,寿命长
•整体模块式便于更换
•可通过堵头堵塞出口使下一个出口的排量成倍增长
•*多出口数量可达22个
•碳钢或不锈钢材质可选
•个各出油口相互关联,系统监控非常简便
技术参数:
出口数量6～22 个出口可选
*高工作压力350BAR
出口间*高相差压力100BAR
每出口每行程排量0.2 毫升
出口接头LINCOLN 专用接头
入口螺纹R1/8(BSPP)内螺纹
工作温度-25℃～70℃
材质碳钢、不锈钢303、不锈钢316 可选
普通SSV系列递进式分配器
订货号型号 出口数量         碳钢                 不锈钢303             不锈钢316
SSV6        6             619-26473-1            619-27471-1         619-27824-1
SSV8        8             619-25730-2            619-27473-1         619-27825-1
SSV10      10             619-26841-1            619-27475-1         619-27889-1
SSV12      12             619-25731-2            619-27477-1         619-27900-1
SSV14      14             619-28862-1            619-29063-1
SSV16      16             619-28863-1            619-29064-1
SSV18      18             619-28864-1            619-29065-1
SSV20      20             619-28865-1            619-29066-1
SSV22      22             619-28866-1
带工作状态指示针的SSV-K系列递进式分配器
订货号型号       出口数量             碳钢不锈钢303           不锈钢316
SSV6-K              6                  619-26474-1           619-27472-1             619-28840-1
SSV8-K              8                  619-25734-2           619-27474-1             619-28841-1
SSV10-K            10                  619-26842-1           619-27476-1             619-28842-1
SSV12-K            12                  619-25755-2           619-27477-1             619-28843-1
SSV14-K            14                  619-28871-1           619-29067-1
SSV16-K            16                  619-28872-1           619-29068-1
SSV18-K            18                  619-28873-1           619-29069-1
SSV20-K            20                  619-28874-1           619-29074-1
SSV22-K            22                  619-28875-1
带接近开关的SSV-N系列递进式分配器
订货号型号     出口数量            碳钢                 不锈钢303
SSV6-N             6               619-28257-1           619-29003-1
SSV8-N             8               619-28258-1
SSV10-N           10               619-28259-1           619-28529-1
SSV12-N           12               619-28260-1           619-29004-1
SSV14-N           14               619-28890-1
SSV16-N           16               619-28907-1
SSV18-N           18               619-28957-1
SSV20-N           20               619-28935-1

带底板的SSV-FL系列递进式分配器（入口G3/8、出口G1/4内螺纹）
出口数量         带指示针的型号        订货号         带传感器的型号              订货号
1                SSV1-FL-K          619-40646-1          SSV1-FL-KN             619-40678-1
2                SSV2-FL-K          619-40646-2          SSV2-FL-KN             619-40678-2
3                SSV3-FL-K          619-40646-3          SSV3-FL-KN             619-40678-3
4                SSV4-FL-K          619-40646-4          SSV4-FL-KN             619-40678-4
5                SSV5-FL-K          619-40646-5          SSV5-FL-KN             619-40678-5
6                SSV6-FL-K          619-40646-6          SSV6-FL-KN             619-40678-6
7                SSV7-FL-K          619-40646-7          SSV7-FL-KN             619-40678-7
8                SSV8-FL-K          619-40646-8          SSV8-FL-KN             619-40678-8
9                SSV9-FL-K          619-40646-9          SSV9-FL-KN             619-40678-9
10              SSV10-FL-K          619-40647-1          SSV10-FL-KN            619-40679-1
11              SSV11-FL-K          619-40647-2          SSV11-FL-KN            619-40679-2
12              SSV12-FL-K          619-40647-3          SSV12-FL-KN            619-40679-3
