美国林肯递进式分配器林肯619-40646-8

供应 Lincoln P203-8XLBO-1K7-24  润滑系统泵站，林肯619-40646-8递进式分配器
水泥厂篦冷机用润滑泵   655-46472-3   P205-M070-5XL-2K7-380-420

供应 Lincoln P203-8XLBO-1K7-24  润滑系统泵站

供应 Lincoln P203-8XLBO-1K6-24  润滑系统泵站

供应 Lincoln P203-8XLBO-1K7-24  润滑系统泵站

644-40666-2 润滑泵

644-40550-7润滑泵
ControlSettings
IntervalBetween Alarm ReservoirCapacity
LubeCycle Time
ModelNo. Description Power Min. Hrs. Min. Liters In 3 Lbs.
94222 P203-2XL-1K6-24-2A6.15-M13-A+SV 24 VDC 4 - 60 1 -15 5 or 30 2 122 4
94422 P203-4XLBO-1K6-24-2A6.15-M13-A+SV 24 VDC 4 - 60 1 -15 5 or 30 4 244 8
94822 P203-8XLBO-1K6-24-2A6.15-M13-A+SV 24 VDC 4 - 60 1 -15 5 or 30 8 488 16
644-40821-6 P203-2XLBO-1K6-12-2A6.15-M08 12 VDC 4 - 60 1 -15 5 or 30 2 122 4
644-40843-8* P203-4XLBO-1K6-12-2A6.15-M08 12 VDC 4 - 60 1 -15 5 or 30 4 244 8
644-40822-8* P203-8XLBO-1K6-12-2A6.15-M16 12 VDC 4 - 60 1 -15 5 or 30 8 488 16
644-40873-1* P203-8XLBO-1K6-AC-3A5.01-M08 120 VAC 4 - 60 1 -15 5 or 30 8 488 16
** Contact Lincoln for 15-liter reservoir models.
Model Specifications
*These"644-"pumpsdonotcomewiththepressurereliefvalve.Itmustbeorderedseparatelyandisrecommended.The1/8"NPTadapter
(304-19614-1)isalsonotincludedandmustbeorderedseparately,ifrequired.

Model Description Cap. or level circuit
No. Oil control board
644-46073-5 P203-2XNBO-1K6-AC-1A1.01-V10 2 liter Grease No Yes
(UL)-A+SV
644-46173-4 P203-4XNBO-1K6-AC-1A1.01-V10 4 liter Grease No Yes
(UL)-A+SV
644-46173-5 P203-4YLBO-1K6-AC-1A1.01-V10 4 liter Oil Yes Yes
(UL)-A+SV
644-46073-6 P203-2XNBO-1K6-AC-1A1.01 (UL)-A+SV 2 liter Grease No No
644-46173-6 P203-4XLBO-1K6-AC-2A1.01 (UL)-A+SV 4 liter Grease Yes No
644-46173-8 P203-4YLBO-1K6-AC-1A1.01 (UL)-A+SV 4 liter Oil Yes No
644-46173-7 P203-4XNBO-1K6-AC-1A1.01 (UL)-A+SV 4 liter Grease No No
644-46174-2 P203-8XLBO-1K6-AC-2A1.01-V10 8 liter Grease Yes Yes
(UL)-A+SV
644-46174-4 P203-8XLBO-1K6-AC-2A1.01 (UL)-A+SV 8 liter Grease Yes No
644-46278-3 P203-15XN-1K6-24-1A5.14-A+SV 15 liter Grease No No
644-46278-1 P203-15XN-1K6-24-1A7.70-V20-A+SV 15 liter Grease No Yes
644-40987-2 P203-15XL-1K6-24-2A6.15-M13-A+SV 15 liter Grease Yes Yes
Model Specifications
Model Power ReservoirCapacity Grease Low-Level Printed
No. Description
Liters In
3
Lbs.
Control CircuitBoard
644-40824-1 P233-2XL-1K6-24-2A5.10-MDF00 24 VDC 2 122 4
644-40824-2 P233-2XLBO-1K6-24-2A5.10-MDF00 24 VDC 2 122 4
644-40826-1 P233-4XLBO-1K6-24-2A5.10-MDF00 24 VDC 4 244 8
644-40827-1 P233-8XLBO-1K6-24-2A5.10-MDF00 24 VDC 8 488 16
644-40868-1 P233-2XL-1K6-12-2A5.10-MDF00-A 12 VDC 2 122 4
Grease Yes Yes
644-40869-1 P233-4XLBO-1K6-12-2A5.10-MDF00-A 12 VDC 4 244 8
644-40870-1 P233-8XLBO-1K6-12-2A5.10-MDF00-A 12 VDC 8 488 16
644-40867-1 P233-8XLBO-1K6-AC-3A6.15-MDF00UL120 VAC 8 488 16

Model Valve Valve
Volt Cable
No. Type Mount
P401 31202574 SSV6 Back 12 VDC 30' / 10m
P401 31402574 SSV6 Back 24 VDC 30' / 10m
P401 42601113 SSV8 Bottom 120 VAC-UL none
P401 42801114 SSV8 Bottom 230 VAC-UL none
P401 61202574 SSV12 Back 12 VDC 30' / 10m
P401 61402574 SSV12 Back 24 VDC 30' / 10m
P401 62601113 SSV12 Bottom 120 VAC-UL none
P401 62801114 SSV12 Bottom 230 VAC-UL none
P401 91202574 SSV18 Back 12 VDC 30' / 10m
P401 91402574 SSV18 Back 24 VDC 30' / 10m
P401 92601113 SSV18 Bottom 120 VAC-UL none
P401 92801114 SSV18 Bottom 230 VAC-UL none

Model Valve Valve
Volt Cable
No. Type Mount
P301 31211154 SSV6 Back 12 DC 30' / 10m
P301 31411154 SSV6 Back 24 DC 30' / 10m
P301 42611113 SSV8 Bottom 120 AC none
P301 42811114 SSV8 Bottom 230 AC none
P301 61211154 SSV12 Back 12 DC 30' / 10m
P301 61411154 SSV12 Back 24 DC 30' / 10m
P301 62611113 SSV12 Bottom 120 AC none
P301 62811114 SSV12 Bottom 230 AC none
P301 91211154 SSV18 Back 12 DC 30' / 10m
P301 91411154 SSV18 Back 24 DC 30' / 10m
P301 92611113 SSV18 Bottom 120 AC none
P301 92811114 SSV18 Bottom 230 AC none

Model Valve Valve
No. Type Mount Volt Cable
P311 31211154 SSV6 Back 12 DC 30' / 10m
P311 61211154 SSV12 Back 12 DC 30' / 10m
P311 91211154 SSV18 Back 12 DC 30' / 10m
P311 31411154 SSV6 Back 24 DC 30' / 10m
P311 61411154 SSV12 Back 24 DC 30' / 10m
P311 91411154 SSV18 Back 24 DC 30' / 10m
P311 42611113 SSV8 Bottom 120 AC none
P311 42811114 SSV8 Bottom 230 AC none
P311 62611113 SSV12 Bottom 120 AC none
P311 92611113 SSV18 Bottom 120 AC none
P311 62811114 SSV12 Bottom 230 AC none
P311 92811114 SSV18 Bottom 230 AC none

Model Valve Valve
Volt Lubricant
No. Type Mount
P301 31411110 SSV6 Back 24 VDC Grease
P301 61411110 SSV12 Back 24 VDC Grease
P301 91411110 SSV18 Back 24 VDC Grease
P311 31411110 SSV6 Back 24 VDC Oil
P311 61411110 SSV12 Back 24 VDC Oil
650-40768-3 SSV8 Bottom 120 VAC Grease
650-40768-4 SSV12 Bottom 120 VAC Grease
650-40768-5 SSV18 Bottom 120 VAC Grease
650-40765-4 SSV8 Bottom 120 VAC Oil
650-40765-5 SSV12 Bottom 120 VAC Oil
650-40765-6 SSV18 Bottom 120 VAC Oil
整体模块递进式分配器
•*高350BAR工作压力,无任何非金属密封,寿命长
•整体模块式便于更换
•可通过堵头堵塞出口使下一个出口的排量成倍增长
•*多出口数量可达22个
•碳钢或不锈钢材质可选
•个各出油口相互关联,系统监控非常简便
技术参数:
出口数量6～22 个出口可选
*高工作压力350BAR
出口间*高相差压力100BAR
每出口每行程排量0.2 毫升
出口接头LINCOLN 专用接头
入口螺纹R1/8(BSPP)内螺纹
工作温度-25℃～70℃
材质碳钢、不锈钢303、不锈钢316 可选
普通SSV系列递进式分配器
订货号型号 出口数量         碳钢                 不锈钢303             不锈钢316
SSV6        6             619-26473-1            619-27471-1         619-27824-1
SSV8        8             619-25730-2            619-27473-1         619-27825-1
SSV10      10             619-26841-1            619-27475-1         619-27889-1
SSV12      12             619-25731-2            619-27477-1         619-27900-1
SSV14      14             619-28862-1            619-29063-1
SSV16      16             619-28863-1            619-29064-1
SSV18      18             619-28864-1            619-29065-1
SSV20      20             619-28865-1            619-29066-1
SSV22      22             619-28866-1
带工作状态指示针的SSV-K系列递进式分配器
订货号型号       出口数量             碳钢不锈钢303           不锈钢316
SSV6-K              6                  619-26474-1           619-27472-1             619-28840-1
SSV8-K              8                  619-25734-2           619-27474-1             619-28841-1
SSV10-K            10                  619-26842-1           619-27476-1             619-28842-1
SSV12-K            12                  619-25755-2           619-27477-1             619-28843-1
SSV14-K            14                  619-28871-1           619-29067-1
SSV16-K            16                  619-28872-1           619-29068-1
SSV18-K            18                  619-28873-1           619-29069-1
SSV20-K            20                  619-28874-1           619-29074-1
SSV22-K            22                  619-28875-1
带接近开关的SSV-N系列递进式分配器
订货号型号     出口数量            碳钢                 不锈钢303
SSV6-N             6               619-28257-1           619-29003-1
SSV8-N             8               619-28258-1
SSV10-N           10               619-28259-1           619-28529-1
SSV12-N           12               619-28260-1           619-29004-1
SSV14-N           14               619-28890-1
SSV16-N           16               619-28907-1
SSV18-N           18               619-28957-1
SSV20-N           20               619-28935-1

带底板的SSV-FL系列递进式分配器（入口G3/8、出口G1/4内螺纹）
出口数量         带指示针的型号        订货号         带传感器的型号              订货号
1                SSV1-FL-K          619-40646-1          SSV1-FL-KN             619-40678-1
2                SSV2-FL-K          619-40646-2          SSV2-FL-KN             619-40678-2
3                SSV3-FL-K          619-40646-3          SSV3-FL-KN             619-40678-3
4                SSV4-FL-K          619-40646-4          SSV4-FL-KN             619-40678-4
5                SSV5-FL-K          619-40646-5          SSV5-FL-KN             619-40678-5
6                SSV6-FL-K          619-40646-6          SSV6-FL-KN             619-40678-6
7                SSV7-FL-K          619-40646-7          SSV7-FL-KN             619-40678-7
8                SSV8-FL-K          619-40646-8          SSV8-FL-KN             619-40678-8
9                SSV9-FL-K          619-40646-9          SSV9-FL-KN             619-40678-9
10              SSV10-FL-K          619-40647-1          SSV10-FL-KN            619-40679-1
11              SSV11-FL-K          619-40647-2          SSV11-FL-KN            619-40679-2
12              SSV12-FL-K          619-40647-3          SSV12-FL-KN            619-40679-3
LINCOLN林肯上海办，美国林肯分配器型号：

LINCOLN		SSV8 单线分配器
LINCOLN		SSV14 单线分配器
LINCOLN		VSG8D2.2 双线分配器
LINCOLN		VSG6D2.2 双线分配器
LINCOLN		VSG4D2.2 双线分配器
LINCOLN		VSG2KR 双线分配器
LINCOLN		VSG4KR 双线分配器
LINCOLN		VSG6KR 双线分配器
LINCOLN		VSL8KR 双线分配器
LINCOLN		SSV12/1 with piston detector				单线计量阀
LINCOLN		VSL2D5.0 双线分配器
LINCOLN		分配器 VSG6-KR,0-2.2cm3
LINCOLN		分配器 VSG8-KR,0-2.2cm3
LINCOLN		分配器 VSG4-KR
LINCOLN		分配块 CG1/4 SN458
LINCOLN		分配块 CG3/8 SN458
LINCOLN		分配器 VSG2-KR,0-2.2cm3
LINCOLN		LINCOLN林肯上海办，美国林肯分配器
LINCOLN		分配块 CG1/2 SN458
LINCOLN		分配块 DG1/2 SN458
LINCOLN		干油分配器 VSL 6-KR				620-40064-3
LINCOLN		干油分配器 VSL 4-KR				620-40062-7
LINCOLN		分配器 VSG8-KR+303-17526-2				0-2.2cm3
LINCOLN		分配器 VSG2-KR+303-17526-2				0-2.2cm3
LINCOLN		600BAR压力传感器
LINCOLN		VSG4-KR 620-40015-3 双线分配器				带2个G3/8和1个G1/4
LINCOLN		VSG6-KR 620-40015-5双线分配器				带1个G1/4堵头
LINCOLN		VSL4-KR 0-5立方米				干油分配器
LINCOLN		VSG 2-KRO-2.2立方米				干油分配器
LINCOLN		VSG2-KR 0-2.2立方米				分配器
LINCOLN		VSG4-KR 0-2.2立方米				分配器
LINCOLN		VSG 4-KR,0-2.2立方米				干油分配器
LINCOLN		VSG8-KR.0-2.2立方米				干油分配器
LINCOLN		VSG8-KR, 0-2.2立方米				分配器
LINCOLN		VSG 8-KR,0-2.2立方米				干油分配器
LINCOLN		VSG 6-KR,0-2.2立方米				干油分配器
LINCOLN		VSG8-KR-2.2				分配器
LINCOLN		VSG4-KR-2.2 分配器
LINCOLN		VSG6-KR-2.2 分配器
LINCOLN		VSG4-KR,0-2.2立方米				干油分配器
LINCOLN		CG1/4 SN458 分配块
LINCOLN		CG3/8 SN458 分配块
LINCOLN		VSG4-KR,0-2.2立方米 分配器
LINCOLN		VSG6-KR,0-2.2立方米 分配器
LINCOLN		VSG8-KR,0-2.2立方米 分配器
LINCOLN		VSG4-KR,0-2.2立方米 干油分配器
LINCOLN		CG1/2 SN458 分配块
LINCOLN		DG1/2 SN458 分配块
LINCOLN		620-40064-3 干油分配器
LINCOLN		620-40062-7 干油分配器
LINCOLN		VSL4-KR, 0-5立方米				干油分配器
LINCOLN		VSG8-KR   林肯分配器
LINCOLN		VSG4-KR (带垫板和螺栓及两个				G3/8堵头) 双线分配器
LINCOLN		VSG8-KR 干油分配器
LINCOLN		VSG6-KR 林肯分配器
83513	84968		11948	84995	27900777
84976	86229		66285	849390	242786
244802	83054		57036	237652	83513
84808	84792		12017	247269	84806
26400631	86233		242546	272596	83834
84902	84793		13227	272856	660-40592-1
241768	272596		13229	P215	600-25047-3
242787	84939		13228	P215	237-13454-1
84908	50051		13235	237651	237-13464-1
84791	241027		241021	236238	34421
84967	66962		84804	252716	247275

LINCOLN林肯泵维修包 84806 |86229| 84976| 83513| 84804| 2322 等多种型号
