Lincoln林肯气动泵82054

 Lincoln P203-8XLBO-1K7-24  润滑系统泵站
水泥厂篦冷机用润滑泵   655-46472-3   P205-M070-5XL-2K7-380-420

供应 Lincoln P203-8XLBO-1K7-24  润滑系统泵站

供应 Lincoln P203-8XLBO-1K6-24  润滑系统泵站

供应 Lincoln P203-8XLBO-1K7-24  润滑系统泵站

644-40666-2 润滑泵

644-40550-7润滑泵

ControlSettings
IntervalBetween Alarm ReservoirCapacity
LubeCycle Time
ModelNo. Description Power Min. Hrs. Min. Liters In 3 Lbs.
94222 P203-2XL-1K6-24-2A6.15-M13-A+SV 24 VDC 4 - 60 1 -15 5 or 30 2 122 4
94422 P203-4XLBO-1K6-24-2A6.15-M13-A+SV 24 VDC 4 - 60 1 -15 5 or 30 4 244 8
94822 P203-8XLBO-1K6-24-2A6.15-M13-A+SV 24 VDC 4 - 60 1 -15 5 or 30 8 488 16
644-40821-6 P203-2XLBO-1K6-12-2A6.15-M08 12 VDC 4 - 60 1 -15 5 or 30 2 122 4
644-40843-8* P203-4XLBO-1K6-12-2A6.15-M08 12 VDC 4 - 60 1 -15 5 or 30 4 244 8
644-40822-8* P203-8XLBO-1K6-12-2A6.15-M16 12 VDC 4 - 60 1 -15 5 or 30 8 488 16
644-40873-1* P203-8XLBO-1K6-AC-3A5.01-M08 120 VAC 4 - 60 1 -15 5 or 30 8 488 16
** Contact Lincoln for 15-liter reservoir models.
Model Specifications
*These"644-"pumpsdonotcomewiththepressurereliefvalve.Itmustbeorderedseparatelyandisrecommended.The1/8"NPTadapter
(304-19614-1)isalsonotincludedandmustbeorderedseparately,ifrequired.

Model Description Cap. or level circuit
No. Oil control board
644-46073-5 P203-2XNBO-1K6-AC-1A1.01-V10 2 liter Grease No Yes
(UL)-A+SV
644-46173-4 P203-4XNBO-1K6-AC-1A1.01-V10 4 liter Grease No Yes
(UL)-A+SV
644-46173-5 P203-4YLBO-1K6-AC-1A1.01-V10 4 liter Oil Yes Yes
(UL)-A+SV
644-46073-6 P203-2XNBO-1K6-AC-1A1.01 (UL)-A+SV 2 liter Grease No No
644-46173-6 P203-4XLBO-1K6-AC-2A1.01 (UL)-A+SV 4 liter Grease Yes No
644-46173-8 P203-4YLBO-1K6-AC-1A1.01 (UL)-A+SV 4 liter Oil Yes No
644-46173-7 P203-4XNBO-1K6-AC-1A1.01 (UL)-A+SV 4 liter Grease No No
644-46174-2 P203-8XLBO-1K6-AC-2A1.01-V10 8 liter Grease Yes Yes
(UL)-A+SV
644-46174-4 P203-8XLBO-1K6-AC-2A1.01 (UL)-A+SV 8 liter Grease Yes No
644-46278-3 P203-15XN-1K6-24-1A5.14-A+SV 15 liter Grease No No
644-46278-1 P203-15XN-1K6-24-1A7.70-V20-A+SV 15 liter Grease No Yes
644-40987-2 P203-15XL-1K6-24-2A6.15-M13-A+SV 15 liter Grease Yes Yes

Model Specifications
Model Power ReservoirCapacity Grease Low-Level Printed
No. Description
Liters In
3
Lbs.
Control CircuitBoard
644-40824-1 P233-2XL-1K6-24-2A5.10-MDF00 24 VDC 2 122 4
644-40824-2 P233-2XLBO-1K6-24-2A5.10-MDF00 24 VDC 2 122 4
644-40826-1 P233-4XLBO-1K6-24-2A5.10-MDF00 24 VDC 4 244 8
644-40827-1 P233-8XLBO-1K6-24-2A5.10-MDF00 24 VDC 8 488 16
644-40868-1 P233-2XL-1K6-12-2A5.10-MDF00-A 12 VDC 2 122 4
Grease Yes Yes
644-40869-1 P233-4XLBO-1K6-12-2A5.10-MDF00-A 12 VDC 4 244 8
644-40870-1 P233-8XLBO-1K6-12-2A5.10-MDF00-A 12 VDC 8 488 16
644-40867-1 P233-8XLBO-1K6-AC-3A6.15-MDF00UL120 VAC 8 488 16

Model Valve Valve
Volt Cable
No. Type Mount
P401 31202574 SSV6 Back 12 VDC 30' / 10m
P401 31402574 SSV6 Back 24 VDC 30' / 10m
P401 42601113 SSV8 Bottom 120 VAC-UL none
P401 42801114 SSV8 Bottom 230 VAC-UL none
P401 61202574 SSV12 Back 12 VDC 30' / 10m
P401 61402574 SSV12 Back 24 VDC 30' / 10m
P401 62601113 SSV12 Bottom 120 VAC-UL none
P401 62801114 SSV12 Bottom 230 VAC-UL none
P401 91202574 SSV18 Back 12 VDC 30' / 10m
P401 91402574 SSV18 Back 24 VDC 30' / 10m
P401 92601113 SSV18 Bottom 120 VAC-UL none
P401 92801114 SSV18 Bottom 230 VAC-UL none
